Object 640 "Black Eagle"



Object 640 "Black Eagle"

1 - view on the port side of the hull
2 - longitudinal section along the axis of the tank's body
24 - left side
25 - starboard side
26 - bottom
27 - upper front sheet
28 - lower front plate
29 – rear hull plate
30 - roof
40, 41 - removable protective screens
43 – motor and transmission compartament
44 - armored pit of driver's hatch
45 - combined module on the upper frontal hull with the inclusion
of passive armor and reactive armor






Object 640 "Black Eagle"

1 - armored hull without turret (top view)


2 - Cross-sectional view hull


3 - section of the hull nose with additional protection and fuel tank compartments


17 - driver's hatch
24 - left side
25 - right side
26 - bottom
30 - roof
31, 32 - track shelves
33, 34 - vertical armor plates installed parallel to the axis of the tank
35, 36, 37 - isolated compartments
38 - anti-fragmentation lining
39 - anti-radiation lining
39 - anti-radiation lining
40, 41 - removable protective screens
42 – side screens with explosive reactive armor
45 - combined module on the upper frontal hull with the inclusion
of passive armor and reactive armor
